WiiM Pro Plus Network Streamer

WiiM Pro Plus Network Streamer

Top-tier audio streamer with high-quality sound and wireless multi-room/multi-channel streaming.

What are the differences between the WiiM Pro and the WiiM Pro Plus

Better ADC for Line Input

It uses TI Burr-Brown Audio PCM1861 ADC, achieving up to 192kHz/32-bit digital output, 110 dB SNR. Thus, it provides high-fidelity analog to digital conversion for input from a record player, MP3 player, or TV.

Ultra-low Noise Clock, Power, and Circuit Design

It uses an ultra-low noise clock, power supply, and careful PCB layout to achieve less than –110dB THD+N performance for analog audio output.

AKM DAC and TI OP AMP for Better Line-Out Audio Quality

It features a new generation AKM 4493SEQ premium DAC that is able to achieve a leading level of low distortion and wide dynamic range thanks to AKM’s Velvet Sound Technology. It supports up to 768 kHz PCM, and DSD512, with PCM/DSD automatic switching ideal for the latest high-resolution audio source. Achieve 120 dB (A-wt) SNR, THD+N of 0.00032% (-110 dB) from 44.1k to 192k.

Line-out performance

SNR： 120dB (A-wt)
THD+N(1 kHz)： 0.00032% (-110 dB) for 44.1k to 192k
FR curve： +/-0.05dB

Make your audio system smart

The WiiM Pro is an audiophile-grade streamer that includes AirPlay 2, Chromecast, DLNA, Spotify Connect, TIDAL Connect, Bit-Perfect audio, Alexa, and multi-room audio.

The WiiM Pro transforms your existing stereo system into a smart one, allowing you to play all your favorite songs from your music apps, the WiiM app, or via voice control using Alexa, Google Voice, or Siri.

Multi-room

The WiiM Pro's built-in multi-room feature allows music streaming throughout your home. For Apple products, you can use Airplay 2 as a multi-room system. If you use an Amazon product, you can utilize AVS Multiroom technology. Finally, WiiM also offers an app for easy management of multi-room setup with your smartphone.

All audio to the same streamer

When connected to the network, you can play audio from many popular services directly to your active speakers. Alternatively, wireless Bluetooth audio streaming is also possible.

Easy connections

The WiiM Pro can be connected to active speakers or an amplified speaker system via Coaxial connection, RCA connectors, or SPDIF connection. The WiiM Mini is powered by a USB-C connection.

Features:

• RCA-RCA cable 1.5m
• Optical cable 1.5m
• USB power cable
• RCA input and output
• Apple AirPlay 2, Google Chromecast Audio
• Spotify Connect/TIDAL Connect/Amazon Music cast
• Touch control
• Optical input
• Digital coaxial output
• Optical SPDIF output
• Dimensions: 140x140x42 mm, 330 g
