MATCH M 2.1AMP – 2-kanavainen/mono-vahvistin

Match M 2.1AMP

The new M 2.1AMP is a true powerhouse in terms of output, yet its size is comparable to a smartphone. Extremely compact installation: In modern vehicles, the space available for audio enhancements is increasingly limited, posing new challenges for installers. Thanks to its small dimensions, the M 2.1AMP can be installed even in the most challenging space conditions, giving you new possibilities for choosing an installation location.
Switchable mono/stereo mode makes the M 2.1AMP a versatile tool.
In mono mode, it is ideal for controlling subwoofers. In stereo mode, it is the perfect choice for driving front or rear speaker systems.
The M 2.1AMP also supports the High-Res audio codec.

Technical data:
Power RMSMono ModeStereo Mode
- @ 4 Ohms1 x 210 Watts2 x 170 Watts
- @ 2 Ohms1 x 350 Watts-
- @ 1 Ohm--
- bridged @ 4 Ohms--
- bridged @ 2 Ohms--
Max. output power (Mono Mode)
Up to 430 Watts RMS @ 2 Ohms
Amplifier technologyClass HD
Inputs2 x RCA / Cinch
1 x Remote In
Input sensitivityRCA / Cinch 1 - 6 Volts
Input impedance RCA / Cinch10 kOhms
Input impedance highlevel-
Outputs2 x Speaker output
1 x Remote Out
Output voltage RCA / Cinch-
Signal converter for digital input-
Frequency response10 Hz - 40,000 Hz
Bass boost-
Highpass-
Lowpass-
Bandpass-
Subsonic-
Phase-
Slope high- / lowpass-
Slope subsonic / lowpass-
Signal-to-noise ratio digital input-
Signal-to-noise ratio analog input108 dB (A-weighted)
Distortion (THD) 0.02 %
Damping factor100
Operating voltage10.5 - 17 Volts (max. 5 Sec. down to 6 Volts)
Idle current500 mA
Fuse1 x 30 A LP-Mini-fuse (APS)
Power ratingDC 12 V ⎓ 40 A max.
Additional featuresVariable input sensitivity, fully stabilized internal power supply, Start-Stop capability, ground switch, mono / stereo mode
Dimensions (H x W x D)
35 x 85 x 110 mm /
1.34 x 3.35 x 4.33″.
